Precision lathe H25
subcategory：
Zorui series
keyword：
Precision lathe H25
Detailed introduction
| Model | ZD-H25 | |
| Processing capacity | Maximum processing diameter of bar | 25mm |
| Maximum machining diameter | 80 (automatic loading and unloading) | |
| Maximum machining length | 70 (automatic loading and unloading) | |
| system | controller | Mitsubishi |
| Electric spindle | interface | A2-4 |
| Spindle power | 5.5 kw | |
| Spindle center * X-axis skateboard center height | 50mm | |
| Spindle rotation speed | 8000 rpm | |
| itinerary | X-axis | 240mm |
| Z shaft | 240mm | |
| Feed | X-axis ball screw | 2510 |
| Z-axis ball screw | 2510 | |
| Bed | Bed | Flat bed row knife structure |
| cast | Integral cast bed H300 | |
| Machine size | Machine tool area | 1590*1860mm |
| Machine height | 1850 | |
| Machine weight | 1800kg | |
| Standard attachments | Matching | |
| Hollow swing cylinder | Cooling system and high-pressure pump | Automatic bar feeder |
| Boring holder | Oil-water separation mechanism | Automatic chip conveyor |
| Double row tool holder | Fully protected rice gold | Special fixtures |
| Single row tool holder | Automatic lubrication system | Water outlet in the center of the spindle |
| Large capacity water tank | Feeding manipulator and conveyor belt | In-line detection |
| Standard fixture | Chuck/collet | Auto flip |
Machine tool peripheral products
Application
Its products are CNC precision lathes, machining centers, multi-axis compound turning and milling machine series, widely used in pneumatic hydraulic, auto parts, home appliances and sanitary ware, medical equipment and military aviation and other industries.
Packing and transportation
In order to serve new and old users in a full range, reduce costs for users, improve efficiency, and enable users to obtain a return on investment, the company's business involves from machine tool manufacturing, equipment maintenance and technology development, precision manufacturing, machine tool accessories and automated manufacturing services, to solve users in product research and development, manufacturing, precision environmental protection, high precision and high efficiency and other related technical problems;
 |
 |
 |
 |
 |
 |
 |
 |
Customer service
In order to serve new and old users in a full range, reduce costs for users, improve efficiency, and maximize the return on investment, the company's business involves machine tool research and development and manufacturing and machine tool application services, to solve users in product research and development, manufacturing, precision environmental protection, high precision and efficient and other related technical problems, diversified, deep and efficient customer management mechanism.
Cooperative enterprise
Automobile industry
Military industry
Other industries
Certification
Over the years, DeHaotong company has been deeply engaged in research, taking the road of independent research and development and close cooperation with foreign technology, successfully applied for a number of patent technology certification, and won the high-tech enterprise qualification certificate, the company focuses on the development and manufacturing of high precision CNC machine tools, and has passed the ISO9000 international quality system certification;
